Samsung Galaxy Z Fold5
Samsung Galaxy Z Fold5 Detailed Specifications
Contents
- 1 Product Type
- 2 Display Type
- 3 Second Display Type
- 4 Unfolded Display Screen Size
- 5 Processor Type (CPU)
- 6 RAM
- 7 Number of Main Cameras
- 8 Sensor Resolution (2nd Camera)
- 9 Sensor Resolution (3rd Camera)
- 10 Number of Front Cameras
- 11 Sensor Resolution (2nd Front)
- 12 Battery Capacity (Battery Size)
- 13 Technology
- 14 Data Transmission
- 15 Supported Digital Audio Standards
- 16 Sensors
- 17 Included Accessories
Product Type
| Specification | Rating |
|---|---|
| Smartphone | – |
| SM-F946B/DS | – |
| Folder – touch screen, dual screen | – |
| 154.9 mm | Better than 77% |
| 67.1 mm | Worse than 51% |
| 13.4 mm | Worse than 68% |
| 253 g | Worse than 98% |
| Folded – 67.1 mm x 13.4 mm x 154.9 mm Unfolded – 129.9 mm x 6.1 mm x 154.9 mm | – |
| Icy blue | Cream | Phantom black | – |
| Armour Aluminium frame, Corning Gorilla Glass Victus 2 | – |
| Water-resistant | – |
| Yes | Better than 86% |
| IPX8 | – |
| 8 (out of 10) | – |
| 1.244 W/kg (head), 3.12 W/kg (limb), 1.193 W/kg (body) | – |
| USB Type-C – 24 pin USB-C | – |
| Nano SIM, Electronic SIM card (e-SIM) | – |
| Dual-SIM | – |
Display Type
| Specification | Rating |
|---|---|
| OLED display | – |
| Infinity Flex Dynamic AMOLED 2X | – |
| Yes | Better than 91% |
| Inward folding | – |
| 7.6" | Better than 99% |
| 2176 x 1812 pixels | Better than 97% |
| QXGA+ | – |
| 374 ppi | Worse than 63% |
| 21.6:18 | – |
| 1750 cd/m² | Better than 97% |
| 16.7 million colours | Better than 98% |
| HDR10+ | – |
| 120 Hz | Better than 94% |
| 100% DCI-P3 | – |
| Corning Gorilla Glass Victus 2 (scratch resistant glass) | – |
Second Display Type
| Specification | Rating |
|---|---|
| OLED display – colour | – |
| 6.2" | – |
| 2316 x 904 pixels | – |
| 16.7 million colours | – |
Unfolded Display Screen Size
| Specification | Rating |
|---|---|
| 7.6 in | – |
| 2176 x 1812 pixels | – |
Processor Type (CPU)
| Specification | Rating |
|---|---|
| Qualcomm Snapdragon 8 Gen 2 | – |
| 3.36 GHz | Better than 99% |
| 8-core | Better than 99% |
RAM
| Specification | Rating |
|---|---|
| LPDDR5X SDRAM – 12 GB | Better than 99% |
| 256 GB | Better than 98% |
| 216.1 GB | – |
Number of Main Cameras
| Specification | Rating |
|---|---|
| 3 | – |
| 50 Megapixel | Better than 96% |
| Wide-angle lens | – |
| F/1.8 | Better than 80% |
| 85 degree(s) | Better than 88% |
| 1 μm | – |
| Optical Image Stabiliser (OIS) | Better than 87% |
| Automatic | – |
| Yes | – |
| Nightography, Capture View, Astro Hyperlapse | – |
| LED flash | – |
| 7680 x 4320 (8K) at 30fps | – |
| RAW image capture, Dual Pixel Autofocus technology, AI Super Resolution, Dual preview, Auto FPS | – |
Sensor Resolution (2nd Camera)
| Specification | Rating |
|---|---|
| 12 Megapixel | Better than 81% |
| Ultra wide-angle lens | – |
| F/2.2 | Better than 87% |
| 123 degree(s) | Better than 97% |
| 1.12 μm | Better than 55% |
Sensor Resolution (3rd Camera)
| Specification | Rating |
|---|---|
| 10 Megapixel | Better than 72% |
| Telephoto lens | – |
| F/2.4 | Better than 76% |
| 36 degree(s) | – |
| 1 μm | – |
| Optical Image Stabiliser (OIS) | Better than 98% |
| 3x | – |
| Phase Detect Auto-Focus (PDAF), Space Zoom x30 | – |
Number of Front Cameras
| Specification | Rating |
|---|---|
| 2 | – |
| 10 Megapixel | Better than 71% |
| F/2.2 | Better than 51% |
| 85 degree(s) | Better than 87% |
| 1.22 μm | Better than 94% |
Sensor Resolution (2nd Front)
| Specification | Rating |
|---|---|
| 4 Megapixel | Worse than 56% |
| F/1.8 | Better than 93% |
| 80 degree(s) | – |
| 2 μm | Better than 90% |
| Under display camera | – |
Battery Capacity (Battery Size)
| Specification | Rating |
|---|---|
| 4400 mAh | Better than 89% |
| Qualcomm Quick Charge 2.0, Adaptive Fast Charging, Samsung Super Fast Charging | Better than 86% |
| Yes | Better than 91% |
| WPC, Qi, Fast Wireless Charging 2.0, Wireless PowerShare | – |
| 2400 minutes | Better than 97% |
| Active online usage (LTE): up to 17 hrs Active online usage (Wi-Fi): up to 18 hrs Playback (wireless video): up to 21 hrs Playback (wireless audio): up to 73 hrs Talk (4G): up to 2400 min | – |
Technology
| Specification | Rating |
|---|---|
| WCDMA (UMTS) / GSM | – |
| 5G | Better than 99% |
| Android 13 | – |
| One UI 5.1.1 | – |
| Bixby | – |
| Samsung Pay | – |
| GPS, GLONASS, BeiDou, Galileo, QZSS | – |
Data Transmission
| Specification | Rating |
|---|---|
| FDD-LTE, TDD-LTE, 5G NR FR1 | – |
| 850 GSM, 900 GSM, 1800 GSM, 1900 GSM | – |
| Band 1, Band 2, Band 4, Band 5, Band 8 | – |
| 2100, 1900, 1700, 850, 900 | – |
| Band 1, Band 2, Band 3, Band 4, Band 5, Band 7, Band 8, Band 12, Band 13, Band 17, Band 18, Band 19, Band 20, Band 25, Band 26, Band 28, Band 32, Band 38, Band 39, Band 40, Band 41, Band 66 | – |
| FDD 2100, FDD 1900 PCS, FDD 1800+, FDD 1700 – 2110 AWS, FDD 850, FDD 2600, FDD 900, FDD 700a, FDD 700c, FDD 700b, FDD 800 lower, FDD 800 upper, FDD 800 DD, FDD 1900+, FDD 850+, FDD 700 APT, FDD 1500 L, TDD 2600, TDD 1900, TDD 2300, TDD 2500, FDD 1700 – 2110 AWS-3 | – |
| N1, n2, n3, n5, n7, n8, n20, n28, n38, n41, n66, n75, n77, n78, n40, n25, n12 | – |
| FDD 2100, FDD 1900PCS, FDD 1800, FDD 850, FDD 2600, FDD 900, FDD 800, FDD 700APT, TDD TD 2600, TDD TD 2500, FDD AWS-3, SDL DL 1500+, TDD TD 3700, TDD TD 3500, TDD 2300, FDD 1900, n12 | – |
| IEEE 802.11a/b/g/n/ac/ax, Wi-Fi 6E | – |
| Bluetooth 5.3 | – |
| Yes | Better than 98% |
Supported Digital Audio Standards
| Specification | Rating |
|---|---|
| WAV, AAC, AMR, MP3, FLAC, XMF, OGG, MIDI, APE (Monkey's Audio), M4A, DSF, MXMF, OGA, 3GA, AWB, IMY, RTTTL, RTX, OTA, DFF, MID | – |
| MKV, FLV, AVI, 3GP, M4V, WebM, 3G2, MP4 | – |
Sensors
| Specification | Rating |
|---|---|
| Accelerometer, proximity sensor, barometer, gyro sensor, hall sensor, geomagnetic sensor, light sensor | – |
| Face recognition, fingerprint reader (side) | – |
| Multitasking, Multi Window, MIMO technology, Samsung KNOX, Samsung DeX support, Samsung Smart Switch, dual battery, Flex mode, Samsung Knox Vault, S Pen support, taskbar | – |
Included Accessories
| Specification | Rating |
|---|---|
| SIM card removal tool, USB-C cable | – |
| VDE, HAC (Hearing Aid Compatible), IPX8, IEC 61960 | – |
| 1.5 m | – |
